2SC5200 PWM Generator Module for Stepper Motor Driver with Forward and Reverse Function

The 2SC5200 PWM Stepper Motor Driver Module is a high-power PWM-based motor control board designed for speed and power regulation of DC motors and stepper motor coils. Built around the 2SC5200 high-current power transistor, this module supports wide voltage input and delivers smooth, efficient PWM control using an onboard potentiometer. It is suitable for DIY motor control projects, automation systems, and power electronics experiments where adjustable speed or power control is required.

Technical Specifications:

• Power Transistor: 2SC5200
• Control Method: PWM (Pulse Width Modulation)
• Input Voltage Range: 12V to 160V DC
• Output Current: High-current drive capability (depends on heat dissipation)
• Control Interface: Onboard potentiometer knob
• Frequency Control: Adjustable PWM frequency
• Protection: Basic overcurrent and thermal tolerance (external protection recommended)
• Mounting: PCB mount with terminal blocks
• Board Type: Motor driver / power control module

Features:

• Wide DC voltage input support
• High-power 2SC5200 transistor for heavy loads
• Smooth and efficient PWM speed control
• Onboard potentiometer for easy adjustment
• Compact PCB design with screw terminals
• Suitable for continuous operation with proper heat sinking
• Ideal for experimental and industrial control setups

Applications:

• DC motor speed control
• Stepper motor coil driving
• PWM power regulation projects
• Automation and robotics systems
• DIY electronics and prototyping
• Industrial motor control experiments
• Power electronics training and testing
