3144E Hall Sensor Magnetic Sensor Module

The 3144E Hall Effect Magnetic Sensor Module is a compact magnetic field detection module based on the 3144E unipolar Hall-effect sensor IC. It is designed to detect the presence of a magnetic field from a permanent magnet without physical contact. When a magnetic field of sufficient strength is detected, the module provides a digital output signal. It operates on a 3.3V to 5V DC supply, making it compatible with popular microcontrollers such as Arduino, ESP8266, ESP32, Raspberry Pi, and other embedded systems. The module is built on an MH-Sensor-Series PCB and includes a standard pin interface for easy integration.

Technical Specifications:

• Sensor IC: 3144E Hall Effect Sensor
• Operating Voltage: 3.3V to 5V DC
• Output Type: Digital Output (DO)
• Operating Current: Approximately 4–10 mA
• Magnetic Sensitivity: Unipolar
• Switching Type: Non-contact magnetic detection
• Response Time: Fast switching in microseconds range
• Operating Temperature: -40°C to +85°C
• Interface Pins: VCC, GND, DO
• Board Type: MH-Sensor-Series

Features:

• Non-contact magnetic field detection
• High sensitivity and fast response time
• Low power consumption
• Stable and reliable performance
• Compatible with 3.3V and 5V logic systems
• Easy interfacing with microcontrollers
• Compact PCB design
• Long operational life due to no mechanical wear

Applications:

• Proximity sensing
• Magnetic field detection
• Speed measurement and RPM counting
• Position sensing
• Door and window open–close detection
• Motor control systems
• Security systems
• Industrial automation
• Robotics projects
• DIY electronics and educational applications
