7Semi BMA400 3-Axis Digital Accelerometer Breakout STEMMA QT / Qwiic

The 7Semi BMA400 3-Axis Digital Accelerometer Breakout is a compact motion-sensing module based on the Bosch BMA400 ultra-low-power MEMS accelerometer. It provides high-efficiency 3-axis acceleration measurement with selectable ranges and includes onboard step-counting and activity-recognition capabilities. The board supports I²C communication and features a Qwiic / STEMMA QT connector for easy plug-and-play integration into IoT, wearable, smart-home and embedded motion-detection applications.

Technical Specifications:

• Sensor: Bosch BMA400 3-axis MEMS accelerometer

• Measurement Range: ±2 g / ±4 g / ±8 g / ±16 g

• Resolution: 12-bit digital output

• Output Data Rate: 12.5 Hz to 800 Hz

• Supply Voltage: 1.72 V to 3.6 V

• Typical Active Current: <14.5 µA

• Sleep Mode Current: ~0.8 µA

• Interface: I²C (default) and optional SPI

• I²C Address: 0x14 default, alternate 0x15

• Interrupt Functions: Step counter, tap/double-tap, orientation change, wake-up, motion detection

• Connector Support: Qwiic / STEMMA QT and header pins

• Package Size (sensor die): Approx. 2 × 2 mm

Features:

• Ultra-low-power 3-axis motion sensing suitable for battery-powered systems

• Selectable full-scale measurement ranges for multiple motion profiles

• Built-in step counting and activity recognition

• Qwiic / STEMMA QT plug-and-play connectivity

• Breadboard-friendly header option for prototyping

• Supports both I²C and SPI interfaces

Applications:

• Wearable devices and fitness tracking

• Smart-home and IoT motion-detection systems

• Portable and battery-operated electronics

• Robotics and drone orientation or vibration sensing

• Industrial vibration and tilt monitoring

• Intrusion detection and automation systems
