7Semi BME688 Environmental Sensor Nano Breakout 2.54mm Pitch Header
7Semi BME688 Environmental Sensor Nano Breakout 2.54mm Pitch Header
The 7Semi BME688 Environmental Sensor Nano Breakout (2.54mm Pitch Header) is a compact, multifunctional environmental sensing module powered by the Bosch BME688 sensor. It combines gas sensing, barometric pressure, temperature, and humidity measurements in a single nano-sized board. With a standard 2.54mm pitch header, it is fully breadboard-friendly and easy to integrate into IoT, prototyping, and embedded applications. Its AI-enabled gas sensing capabilities make it suitable for advanced air-quality analysis and environmental monitoring.
Technical Specifications:
- Sensor IC: Bosch BME688
- Measurement Parameters: Gas, Pressure, Temperature, Humidity
- Interface: I²C (standard), SPI supported by the sensor
- Supply Voltage: 3.3V
- Temperature Range: -40°C to +85°C
- Humidity Range: 0% to 100% RH
- Pressure Range: 300 hPa to 1100 hPa
- Gas Sensing: VOCs, VSCs, general air-quality detection with AI-based gas scanning
- Gas Scan Speed: ~10.8 seconds per scan
- Humidity Response Time: ~8 seconds (T63%)
- Humidity Accuracy: ±3% RH (typical)
- Pressure Noise: ~0.12 Pa RMS (≈1.7 cm altitude resolution)
- Pressure Sensitivity Error: ±0.25%
- Header Pitch: 2.54mm standard
- Output Type: Digital calibrated output
- Operating Temperature: -40°C to +85°C
- Form Factor: Nano breakout board for compact projects
Features:
- 4-in-1 environmental sensing: temperature, humidity, pressure, and gas
- AI-powered gas detection for VOCs and other volatile compounds
- Compact nano-sized breakout with 2.54mm pitch for easy prototyping
- Digital I²C interface ensures simple communication with microcontrollers
- Suitable for breadboards, perfboards, and custom PCBs
- Wide operating range for both indoor and outdoor applications
- Reduces the need for multiple sensors in environmental monitoring projects
- Ideal for IoT, smart home, and embedded devices
- Low power consumption for portable or battery-powered systems
- Compatible with Arduino, ESP32, Raspberry Pi, STM32, and other platforms
Applications:
- Indoor air quality monitoring
- Smart home and IoT systems
- Environmental and climate stations
- Industrial safety and atmospheric monitoring
- Portable environmental sensing devices
- Data logging and research experiments
- Greenhouse and horticulture environment control
- Weather monitoring and barometric pressure measurement
- HVAC automation and control systems
- Consumer and wearable environmental devices
