7Semi SOT23-6 SOT23-3 SC70-6 Breakout Adapter PCB

The 7Semi SOT23-6 / SOT23-3 / SC70-6 Breakout Adapter PCB is a compact and versatile adapter board designed to convert small SMD (surface-mount) IC packages into a DIP (Dual Inline Package) format. It allows easy integration of SOT23 and SC70 components into standard breadboards, perfboards, or through-hole PCBs for prototyping and testing. This breakout board is ideal for developers, engineers, and hobbyists who need to interface or test small SMD components without specialized reflow equipment.

Technical Specifications:

• Supported Packages: SOT23-6, SOT23-3, SC70-6
• Board Type: Double-sided adapter PCB (SMD pads on one side, DIP layout on the other)
• DIP Pitch: 2.54 mm (compatible with standard breadboards)
• Pad Pitch (SMD Side): 0.95 mm (SOT23) / 0.65 mm (SC70)
• Material: High-quality FR-4 PCB substrate
• Finish: Gold-plated or tin-plated pads for better solderability
• Dimensions: Compact, breadboard-friendly design
• Color: Green solder mask with clear white silkscreen labels
• Operating Temperature: -40°C to +85°C
• Mounting Type: Solder mount for SMD components and through-hole pins for DIP conversion

Features:

• Supports multiple small SMD packages on a single board
• Converts SMD parts to standard 2.54 mm DIP format
• Double-sided layout for flexible usage options
• Clear silkscreen labeling for easy pin identification
• High-quality PCB ensures durability and precision
• Gold/tin plating provides strong solder joints and corrosion resistance
• Compatible with breadboards, prototyping boards, and DIP sockets
• Ideal for rapid testing and prototyping of small ICs and transistors

Applications:

• Prototyping and testing of SMD components
• Converting SOT23 and SC70 ICs for use on DIP or breadboard circuits
•  Educational and training projects for electronics students
• Repair and replacement of miniature ICs in existing circuits
• Development of custom circuits using SMD components
• Laboratory and R&D use for IC evaluation and circuit testing
