ADXL346 3-Axis Digital Accelerometer
Accelerometer as the name implies measures proper acceleration aka g-force. Triple axis accelerometer measures the vector components of the g-force which means it can detect tilts. Gyroscope on the other hand detects orientation. Unlike accelerometer gyroscopes are not affected by gravity.
Technical Specification:
- Supply Voltage: 3.3 V/ 5V
- Interface Type: I²C, SPI
- Sensing Range: ±2g, ±4g, ±8g, ±16g
- Sensitivity:
- X: 28.6 LSB/g
- Y: 31.2 LSB/g
- Z: 34.5 LSB/g
- Ultra Low Power: 40µA in measurement mode, 0.1µA in standby@ 2.5V
Features:
- Freefall detection
- Single tap double tap detection
- Activity inactivity monitoring
- Flexible interrupt modes mappable to either interrupt pin
Applications:
- Mobile phones
- Handsets
- Gaming instruments
- Drones
- Hard disc protection
- Navigation devices
Product Information
