The FT2232HL Development Board is a versatile USB interface development board based on the FTDI FT2232HL dual-channel USB 2.0 Hi-Speed controller. It provides two independent multi-purpose channels that can be configured for UART, FIFO, SPI, I²C, JTAG, or bit-bang modes. The board is designed for developers, engineers, and students who need a reliable USB-to-serial or USB-to-JTAG/SPI interface for debugging, programming, and communication with embedded systems. It is widely used for FPGA, MCU, and processor development.
Technical Specifications:
- Controller IC: FTDI FT2232HL
- USB Interface: USB 2.0 Hi-Speed (480 Mbps)
- Channels: Dual independent channels (Channel A & B)
- Operating Voltage: 5 V from USB
- I/O Voltage: 1.8 V / 3.3 V / 5 V (selectable via onboard configuration)
- Supported Modes: UART, FIFO, SPI, I²C, JTAG, Bit-Bang
- USB Connector: USB Type-B
- On-board Components: EEPROM, voltage regulators, LEDs, jumpers
- Header Pins: Exposed I/O pins for both channels
- OS Support: Windows, Linux, macOS
- Driver Support: FTDI VCP and D2XX drivers
Features:
- Dual-channel USB interface on a single board
- High-speed USB 2.0 communication
- Supports multiple communication protocols
- Ideal for JTAG and SPI based debugging
- On-board LEDs for status indication
- Flexible I/O voltage support
- Plug-and-play with FTDI drivers
- Robust design suitable for development and testing
Applications:
- FPGA programming and debugging
- Microcontroller communication and flashing
- JTAG interface for embedded systems
- USB-to-UART, USB-to-SPI, USB-to-I²C converters
- Industrial and automotive electronics development
- Embedded system prototyping
- Educational and research projects
