The MS833 Digital Multimeters are designed for contactless measurement of AC voltage, DC voltage, resistance, battery, DC current and test diodes.

Technical Specification:

• Brand : Mastech
• Model : MS833
• Display Type : Digital
• Display Count : 1999, 3 1/2 Digits
• Selection of Measuring Ranges : Manual
• Overload Display : OL
• DC Voltage Measuring Range : 0.2V ~ 600VDC
• Indication error : ± 0.5%
• Maximum AC Voltage Measuring Range : 200V ~ 600VAC
• Indication error : ± 0.5%
• Resistance Measuring Range : 200? ~ 2 M?
• Indication error : ± 1.5%
• Safety Standards : CATII 600V
• Operating Temperature Range : 0 ~ +40°C
• Memory mode (Hold) : No
• Display backlight : No
• Automatic shutdown : No
• Sound signals : No
• Size: 125x65x32 mm
• Weight: 220 gm

Features:

• Compact and lightweight
• 2 meters drop test
• Precision protection
• Comfortable protective cover
• With test lead hanging groove
• With full overload protection
• With low battery indication

Pin Description:

Applications:

• Can be used to diagnose, assemble, and repair circuitry and wiring
• Automotive
• Electrical work
• DIY Projects
• Laboratories

Package Includes:

• Mastech MS833 Digital Multimeter
• User’s Manual
• Test Leads ( one pair)
