This TCS3200 color sensor module consist of a TAOS TCS3200 RGB sensor chip and 4 white LEDs. The main part of the module is the TCS3200 chip which is a Color Light-to-Frequency Converter. The white LEDs are used for providing proper lighting for the sensor to detect the object colour correctly. This chip can sense a wide variety of colours and it gives the output in the form of corresponding frequency.

Technical Specification:

• Input voltage: (2.7V to 5.5V)
• Interface: Digital TTL
• Working temperature: -40°C to 85°C
• Size: 28.4mm*28.4mm (L*W)

Features:

• High-resolution conversion of light intensity to frequency
• Programmable colour and full-scale output frequency
• No need of ADC (Can be directly connected to the digital pins of the microcontroller)
• Power down feature

 Applications:

• Colour sorting robots
• Test strip reading
• Colour matching tests
