Tesla Coil Module

The Tesla Coil Module is a compact high-voltage generator designed to produce visible electrical arcs and electromagnetic effects using a low-voltage DC input. It operates by rapidly switching current through a primary coil to induce a very high voltage in the secondary coil. This module is commonly used for science demonstrations, educational experiments, and hobby electronics to showcase principles of resonance, induction, and high-frequency electricity.

Technical Specifications:

• Input Voltage: 12 V DC (typical)
• Input Current: Up to 2 A (varies with load and tuning)
• Output Voltage: High-voltage AC (tens of kilovolts, approximate)
• Operating Frequency: High-frequency oscillation
• Coil Type: Integrated secondary coil with copper winding
• Control: On-board driver circuit
• Adjustment: On-board trimmer for tuning
• Board Type: Ready-to-use assembled module
• Cooling: Passive (heat sink provided on driver transistor)

Features:

• Generates high-voltage electric arcs
• Compact and easy-to-use module
• Operates from low-voltage DC supply
• On-board driver and tuning control
• Suitable for demonstrations of wireless energy effects
• Durable coil winding and solid PCB design
• Ideal for hobbyist and educational use

Applications:

• Science and physics demonstrations
• Educational experiments on electromagnetism
• High-voltage and resonance learning projects
• Hobby electronics and DIY projects
• Visual arc display experiments
• Tesla coil learning kits
• STEM education and workshops
