The 40×1 10 mm 2.54 mm Pitch Right Angle Female Pin Header is a single-row through-hole connector designed for horizontal (90-degree) PCB connections. It features 40 female contacts in a standard 2.54 mm pitch with a 10 mm insulated body height, allowing signals or power to be routed parallel to the PCB surface. This makes it ideal for space-saving layouts, side-entry connections, and modular electronics where vertical clearance is limited.

Technical Specification:

• Product Type: Right Angle Female Pin Header

• Configuration: 1 × 40 pins

• Pitch: 2.54 mm (0.1 inch)

• Insulator Height: 10 mm

• Mounting Type: Through-hole (THT)

• Pin Orientation: Right Angle (90°)

• Contact Material: Copper alloy

• Contact Plating: Tin-plated or gold-plated (typical)

• Insulator Material: Black thermoplastic

• Rated Current: ~1 A per pin (typical)

• Rated Voltage: Up to 250 V (typical)

• Operating Temperature: −40 °C to +105 °C (typical)

• Cuttable: Yes, can be cut to required pin length

Features:

• Standard 2.54 mm pitch for wide compatibility

• Right-angle design for horizontal PCB connections

• Single-row configuration for compact layouts

• 10 mm body height provides clearance and mechanical strength

• Reliable through-hole soldering for durability

• Compatible with standard 2.54 mm male pin headers

Applications:

• Side-entry PCB connections

• Arduino, ESP32, Raspberry Pi, and development boards

• Board-to-board and board-to-module interfaces

• Prototyping and testing setups

• Embedded systems and industrial electronics
